PRODUCT FEATURES

·       Display: White characters on a blue STN-LCD background.

·       Dimensions: 87.0 mm (W) x 60.0 mm (H) x 12.5 mm (T).

·       Active Area: 56.20 mm x 20.80 mm.

·       Interface: 6800 4-bit or 8-bit parallel communication.

·       Compatible ICs: AIP31066, HD44780, KS0066, SPLC780, ST7066.

·       Backlight: Blue, drawing 45 mA of current.

·       Power Supply: 5V DC with a maximum current of 1800 μA.

·       Operating Temperature: -20°C to 70°C, and storage temperature between -30°C and 80°C.

·       Viewing Direction: 6:00 (best viewed from below).

·       Connection Type: Pin header
